The Complete Food Trailer Equipment Checklist (What Health Inspectors Actually Look For)

Most equipment lists online are written by people who've never stood next to a health inspector. This one is organized the way an inspection actually flows — because if a system on this list is missing or undersized, you don't open. It's also the exact spec we build into every trailer at Food Trailer Pros.

1. Plumbing and water (the #1 failure area)

• 3-compartment sink — large enough to fully submerge your biggest utensil or pan. Wash, rinse, sanitize. Undersized sinks are a classic inspection failure.
• Dedicated handwash sink — separate from the 3-compartment, with soap and paper towels. Never share duties.
• Hot water heater — hot water under pressure at every sink. Our standard is a 6-gallon electric unit.
• Fresh water tank + wastewater tank, labeled — and here's the rule that catches people: the wastewater tank must be at least 15% larger than the fresh tank (Texas and most states). Our standard pairing: 30-gal fresh / 40-gal waste.
• Automatic water pump — consistent pressure without shore hookups, because inspectors test your unit running self-contained.

2. Ventilation and fire (the #2 failure area)

• Type I commercial hood with exhaust fan — mandatory over any grease-producing cooking (fryers, flat tops, grills), sized to your appliances' BTU output.
• Automatic fire suppression system — wet-chemical, UL 300-compliant, nozzles aimed at each appliance, with automatic fuel shutoff and a current service tag. The full requirements deserve their own article:
• Class K extinguisher at the cookline + ABC extinguisher for the rest of the trailer.

3. The cookline (menu-driven — buy for your menu, not the catalog)

Typical serious builds carry some combination of: commercial fryers (a two-fryer setup, e.g. 2×40 lb, is the workhorse for most concepts), a flat top griddle (24"–36"), range or charbroiler as the menu demands. Every appliance you add ripples through the hood size, suppression nozzle count, propane demand, and electrical load — which is why menu-first design saves money.

4. Cold chain

• Reach-in refrigeration sized to your prep volume (a 29" reach-in is a common anchor)
• Sandwich/prep refrigerator — refrigerated rail plus work surface in one footprint; the biggest space-efficiency win in a trailer
• Freezer capacity per your menu
• Everything commercial-grade (NSF-style), with thermometers — inspectors check holding temps first thing.

5. Electrical

• 50-amp panel as the serious baseline — a full cookline plus refrigeration plus AC on a smaller panel means tripped breakers on your busiest day
• Permanent wiring to code (extension cords inside a build are an automatic red flag)
• Interior LED lighting (bright, shatter-protected over food areas) + exterior work lights for night events
• Shore power inlet and, if you'll work off-grid, a properly sized generator on an exterior platform, isolated from food areas.

6. Propane system

• Tanks mounted and secured outside food prep areas, with regulator and leak-tested lines
• Many operators add a 100 lb tank setup for high-BTU cooklines — spec it during the build so lines and regulator match.

7. Climate and structure

• Mini split AC — in Texas, this is equipment, not comfort: a 110°F kitchen breaks staff and stresses refrigeration
• Smooth, light-colored, washable wall/floor/ceiling surfaces (inspectors run a hand along them)
• Stainless prep tables sized to your workflow
• Concession window with proper service configuration; screened openings.

8. Running gear

• Axles matched to real loaded weight: 14 ft and longer means tandem axles — water, propane, and commercial equipment add up fast. 12 ft builds can run a single axle.
• Brakes, breakaway kit, DOT lighting, and a coupler matched to your tow vehicle.

The one-line test

Before you buy any trailer — new or used — ask: "Can this unit run its sinks, hot water, and refrigeration fully self-contained, right now, and does the fire system carry a current tag?" That single question is most of a pre-licensing inspection, and it's exactly what Texas DSHS verifies before issuing the new statewide license.

FAQ

What does the FTP Standard package include? Every build ships with: 3-compartment + handwash sinks, automatic water pump, 6-gal electric water heater, 30/40-gal water tanks, ventilation hood with exhaust fan, fire suppression system, mini split AC, 50-amp panel, interior LED, concession window, and exterior work lights. Cooklines are then customized to your menu.

Can I add equipment later? Structurally yes, but hood, suppression, propane, and electrical must be re-engineered around any new appliance — designing the full menu upfront is always cheaper.

Is used equipment okay? For some items, yes — but refrigeration and suppression systems are where used gear most often fails inspection or dies in month three.
